| ブランド名: | Skyline |
| モデル番号: | SL-FL609 |
| Moq: | 1 |
| 価格: | 交渉可能 |
| 支払い条件: | T/T、L/C、D/A、D/P、Western Union、MoneyGram、現金 |
| 供給能力: | 30ユニット /月 |
| Parameter | Specification |
|---|---|
| Weight of pendulum | 1500g ± 30g |
| Distance from the center of gravity of pendulum to the end | 410mm ± 5mm |
| The static pressure of the rubber sheet on the ground | 22.2N ± 0.5N |
| Sliding length of pendulum on the road surface | 126mm ± 1mm |
| Distance from the lower edge of the rubber sheet to the swing center of the pendulum | 510mm ± 2mm |
| Dimension of rubber sheet | 6.35mm x 25.4mm x 76.2mm |
| Shore hardness of rubber sheet | 55 ± 5 HD |
| Pointer | Weight ≤85g, length 300mm ± 1mm |
| The Angle between the rubber sheet and the horizontal | 26 ± 3° |
| Machine Dimension | 620*450*590mm (About 14kg) |
