| ブランド名: | SKYLINE |
| モデル番号: | SL-Z06B |
| Moq: | 1 |
| 価格: | Negociate |
| 支払い条件: | T/T |
| 供給能力: | 1セット/月 |
| Parameter | Specification |
|---|---|
| Indication Error | ±1% |
| Indication Variability | <1% |
| Resolution | 0.1 N |
| Measurement Range | 0 - 10000 N |
| Deformation Error | ≤ ±1 mm |
| Platen Area | 300×170×300mm |
| Platen Parallelism | ≤1 mm |
| Working Stroke | 5 - 300 mm |
| Sample Length | 300mm |
| Longitudinal Compression Speed | 10 ± 2 mm/min |
| Horizontal Bending Speed | 100 ± 10 mm/min |
| Test Rate Range | 10-100mm/min |
| Accuracy | ±2% |
| Volume (Main Unit) | 55×40×85cm |
| Weight (Main Unit) | 70kg |
| Power Supply | 1∮, AC 220V, 1.5A |
