| ブランド名: | SKYLINE |
| モデル番号: | SL-F11 |
| Moq: | 1 |
| 価格: | 交渉可能 |
| 供給能力: | 15 SETS/MONTH |
| Parameter | Specification |
|---|---|
| Needle Burner | Inner hole diameter Φ0.5mm ± 0.1mm, Diameter ≤Φ0.9mm, length ≥35mm, stainless steel |
| Burner Angle | 0~45° (adjustable for flame height) |
| Thermocouple | Ø0.5mm Type K (Ni/Cr - Ni/Al), armored sheath withstands 40°C~1100°C |
| Burning Time | 0-999.9s ± 0.1s adjustable (typically 30s) |
| Hold Burning Time | 0-999.9s ± 0.1s, automatic recording, manual timeout |
| Flame Height | 12mm ± 1mm (with height measurement instruments) |
| Flame Gas | Butane gas, minimum 95% purity (bottled lighter gases acceptable) |
| Temperature Test Range | 0~1000°C |
| Flame Temperature Requirements | From 100°C ± 2°C to 700°C ± 3°C in 23.5 seconds ± 1 second |
| Standard Copper Block | 4mm ± 0.01mm, weight 0.58g ± 0.01g before drilling, Cu-ETP |
| Test Process | Automatic control with independent convulsions |
| Chamber | ≥0.5m³ |
| Control System | Single chip microcomputer + touch screen control |
| Applicable Standards | GB/T5169.10-2006, IEC60695-11-5:2000, UL746A |
| Power Supply | 800VA, 220V, 48-60Hz |
| Display Panel Language | English (customization available) |
